UNO Screw Shield V1.0


Description :

Arduino ScrewShield V2.0 combines the power of Arduino screw shield and Arduino prototyping shield. This Arduino ScrewShield V2.0 offers a better and more optional way to do prototyping.

The Screw terminal can be screwed directly to the terminal on the thread and is reliable and convenient. It can be plugged into the Arduino controller. You can use this shield to save yourself from the bad port connection. Feel secure with this arduino-compatible screw shield.

Arduino ScrewShield V2.0 provides a fast prototpying area for projects. It features a LED (D13) and two buttons (reset and general).

In the case that you have a breadboard, the shield do not ship with breadboard.  The best suitable breadboard is Mini Bread Board Self Adhesive.





Features :

1)  Combines the power of the screw shield prototyping shield-that Proto screw shield

2)  Expand all of IO interfaces from Arduino

3)  Contain a reset button

4)  Contain a button key which connect with analog interface A5

5)  Contain a LED lights which connect with digital interface D13


Documents :


Schematic Diagram (great assembly and usage hints)
